High Temperature Resistant Rubber Compound Silicone Fiberglass Fabric
Brief Introduction
Silicone Fiberglass Fabric as a high performance and multi-purpose composite new material, is divided into two types: single-side coated and double-side coated. It is made of fireproof, high-temperature-resistant and high strength fiberglass cloth as the base material and brand silicone rubber through coating, calendering and high-temperature heat vulcanization process, which can be used for a long time in the temperature range from - 40℃ to about 200℃.
Typical Application Scenarios of Silicone Fabric
1.Removable pipe insulation jacket, energy-saving insulation jacket, equipment insulation jacket, and pipeline equipment thermal insulation
2.Fan soft connection, non-metallic expansion joints (compensators), fire soft joints
(Note: Silicone rubber can not be used for flue gas and water vapor pipeline compensators containing SO₂ components)
3.Welding Blanket, Welding Blanket, Fire Blanket, Fire Extinguishing Blanket
4.Fireproof insulation curtain, smoke wall curtain, fire curtains
5.Electrical insulating fabric: Silicone fabric has a high electrical insulation grade and can withstand high voltage loads
6.Aerospace, chemical, petroleum, energy, metallurgy, large-scale power generation equipment, electrical insulation, cement, machinery, construction and other fields.
7.Anti-corrosion field: Silicone rubber coated glass fiber cloth can be used as internal and external anti-corrosion layer of pipeline, with excellent anti-corrosion performance and high strength.
8.Building sealing materials, high-temperature anticorrosive conveyor belts, packaging materials and other fields.
Product Specification
| Style |
Thickness |
Width |
Length |
Working Temperature |
Silicone Rubber Side |
Basic Fabric Weave Style |
| (mm) |
(m) |
(m/roll) |
(℉) |
(Single/Double) |
| SRC1.5 |
1.5 |
1/1.2/1.25 |
50 |
500 |
Double |
Twill/Satin |
| SRC2.0 |
2 |
1/1.2/1.25 |
50 |
500 |
Double |
Satin |
| SRC3.0 |
3 |
1/1.2 |
25 |
500 |
Double |
Satin/Plain |
FAQ
1. Q: Are you a silicone coated fiberglass fabric manufacturer or trading company?
A: We are a manufacturer of fiberglass?composite materials,main products are silicone coated fiberglass fabric.
2. Q: How to contact ?
A: You can contact us by mail or phone. Email: zjc@yaoxing.com.cn; Phone number: +86-18251790221(WA)
3. Q: What is your delivery time?
A: Generally it will take 7 to 25 days after receiving your payment bank receipt. The specific delivery time depends on the products and quantity you ordered.
4. Q: Can you produce customized products?
A: We can customize the product according to your requirements, including color, weaving type, thickness, weight, coating, etc.
