Product Details:
|
Product Name: | Silicone Coated Glass Cloth | Material: | E-glass And Liquid Silicone |
---|---|---|---|
Usage: | Welding Protection,insulation Sleeve,fire Curtain | Working Temperature: | -40-280℃ |
Weave Style: | Plain,twill,stain | Color: | Grey,red,black,white And So On |
High Light: | Thickness 0.4mm Silicone Coated Fiberglass Cloth,Twill Silicone Coated Fiberglass Cloth,Twill Silicone Coated Fireproof Fiberglass Fabric |
Thick Silicone Coated Fiberglass Cloth For Fire Insulation Sleeve
1, Description:
Double sided silicone fabric is made of high quality continuous glass fiber cloth and silicone coating. You can make this silicone cloth into a welding blanket. Silicone fabric is more flexible and cost effective, it has more choice for the coated color also. Thick Silicone Coated Fiberglass Cloth can have many color coating options. This fiberglass welding blanket can protects your personnel, equipment and working area while welding. It can provides thermal protection from sparks and spatter very well.Of course, Yaoxing factory also make fireproof blankets and welding blankets. The main products are flame retardant fiberglass fire blankets, silicone fiberglass fire blankets, acrylic fiberglass welding blankets, Polyurethane coated fiberglass fire blanket, graphite coated fiberglass welding blankets, and high silica fireproof blankets
2, Specifications:
Style | Thickness (mm) |
Weight (g/m2) |
Color | Base Cloth (g/m2) |
Weaving Way |
1 | 0.4 | 520 | gray | 310/3731 | twill |
2 | 0.5 | 580 | gray | 430/3732 | satin |
3 | 0.8 | 1000 | gray | 830/3784 | satin |
4 | 1.1 | 1600 | black | 880/3788 | satin |
5 | 1.2 | 1600 | red | 880/3788 | satin |
6 | 1.3 | 1550 | gray | 880/3788 | satin |
7 | 1.3 | 1650 | black | 880/2788 | satin |
8 | 1.5 | 2000 | red | 880/3788 | satin |
9 | 1.6 | 2350 | black | 1350 | satin |
Advantage with silicone rubber and fiberglass fabric:
1. -70°C-280°C high temperature resistance, good low temperature performance;
2. High strength;
3. Resistance to ozone, oxidation, light and weathering and aging;Working temperature is -70°C-300°C
Working temperature is -70°C-300°C
With fire resistance, heat insulation, water resistance, sunlight and weathering aging, the weather resistance can be up to 10 years when used outdoors and in age
Highly insulated
Physical and chemical properties
Application:
expansion joints, welding blanket, smoke curtain, flange covers, welding curtains, safety clothing, equipment covers
Specifications Of Silicone Coated Glass Cloth
Product No |
Silicone Coated Sides |
Basic Fabric Weave Style |
Basic Fabric Weight | Silicone Rubber Weight | Thickness | Width | Length | |||||
oz/yard | g/mtr | oz/yard | g/mtr | inch | mm | Inch | cm | yard | meter | |||
YX-SRC-0.4 | Two | Twill | 13.86 | 430 | 4.19 | 130 | 0.0156 | 0.4 | 40/47/60/72 | 100/120/150/180 | 54.7/109.4 | 50/100 |
YX-SRC-0.6 | Two | Satin | 21.28 | 660 | 7.05 | 200 | 0.0234 | 0.6 | 40/47/60/72 | 100/120/150/180 | 54.7 | 50 |
YX-SRC-0.8 | Two | 8H Satin | 27.08 | 840 | 7.05 | 200 | 0.0312 | 0.8 | 40/47/60/72 | 100/120/150/180 | 54.7 | 50 |
