Product Details:
|
| Product Name:: | Outdoor Extending Silicone Coated Glass Fabric | Thickness:: | 1.5mm,2.0mm,2.5mm,3.0mm |
|---|---|---|---|
| Material:: | Silicone Rubber And Fiberglass Fabric | Features:: | Water Proof |
| Temperature Resistance:: | -70℃-280℃ | Color:: | Red |
| Length:: | 50m/roll | Silicone: | Silicone Side: |
| High Light: | 2.0mm Thickness Silicone Fiberglass Fabric,Silicone Coated Fiberglass Fabric 50m/roll,1.5mm Thickness Silicone Fiberglass Fabric |
||
Silicone Rubber Double-Sided Fiber Cloth Coated Fiberglass Fabric Cloth
3300g M2 Outdoor Extending Silicone Coated Glass Fabric
1. Description with Outdoor Extending Silicone Coated Glass Fabric:
1. Electrical insulation: Silicone cloth has a high level of electrical insulation, can withstand high voltage loads, and can be made into insulating cloth, casing, and other products.
2. Non-metallic compensator: Silicone cloth can be used as a flexible connecting device for pipes, which can solve the damage to pipes caused by thermal expansion and contraction. Silicone cloth has high temperature resistance, corrosion resistance, anti-aging performance, good elasticity and flexibility, can be widely used in petroleum, chemical, cement, energy and other fields.
3. Anti-corrosion: Silicone rubber coated glass fiber cloth can be used as a pipeline, an internal and external anti-corrosion layer for storage, with excellent anti-corrosion performance and high strength, and is an ideal anti-corrosion material.
4. Other fields: Silicone rubber coated glass fiber membrane structure materials can be used in building sealing materials, high temperature anti-corrosion conveyor belts, packaging materials and other fields.
5. Can be used as fire curtain.
2. Specification with Silicone Coated Glass Fabric:
| Thickness(mm) | Colour | Width(m) | Length(m/roll) | Working Temperature(℉) |
Gram per square meter (g/m2) |
Breaking Down Voltage (KV/MM) |
| 1.0 | Red/Black and so on | 1/1.2 | 50 | 500 | 1650 | 20 |
| 1.5 | Red/Black and so on | 1/1.2 | 50 | 500 | 2450 | 25 |
| 2.0 | Red/Black and so on | 1/1.2 | 50 | 500 | 3300 | 30 |
| 2.5 | Red/Black and so on | 1/1.2 | 50 | 500 | 4100 | 40 |
| 3.0 | Red/Black and so on | 1/1.2 | 25 | 500 | 4800 | 50 |
3, characteristics:
1, used in the temperature form -70℃ to 230℃
2, resistant to ozone, oxygen, sunlight and aging, long using life up to 10 years
3, high insulating properties, dielectric constant 3-3.2, breaking down voltage: 20-50KV/MM
4, good flexibility and high surface friction
5, chemical corrosion resistance
Silicone calender coated fabric is designed to provide a excellent smooth surface,the silicone calender coated fabric offers increased tensile strength which allows for using in high temperature(continuously under 500 ℉)and strong pressure(maximum 1000PSI).
By thickness,we have two categories of products.One kind has a thickness of over 1mm and another kind has a thickness of below 1mm.You can choose the thickness by the occasion you use.
More picture with Solicone coated Fiberglass fabric:
